Draw.io MCP Browser Extension

Let's do some Vibe Diagramming with the most wide-spread diagramming tool called Draw.io (Diagrams.net).

This is a necessary counterpart for Draw.io MCP Server

Requirements

Optional for Development

• pnpm - Preferred package manager

Installation

For detailed end-to-end Draw.io MCP installation please follow the description on Draw.io MCP Server.

There are the following options to install the Extension itself.

Web Store

Release package

You can download a ZIP for one of the browsers in the Release section.

GitHub CI package

You can download a ZIP with both versions of the Extension for Chrome and Firefox in the package workflow.

Just open a job run, scroll to the Artifact section, download the ZIP and side load the extension for one of the supported browsers.

Local build

You can build a version of the extension by running:

pnpm run build

or

pnpm run build:firefox

It will build expanded version in the .output folder.

If you need a ZIP/CRX, run one of the following:

pnpm run zip

or

pnpm run zip:firefox

Configuration

WebSocket Server Port

By default, the extension connects to the Draw.io MCP Server on port 3333. You can configure a different port through the extension options:

1. Click on the extension icon to open the popup
2. Click the ⚙️ Settings button (or access extension settings through your browser's extension management page)
3. Enter your desired port number (1024-65535)
4. Click Save Settings

The connection will automatically reconnect with the new configuration. The configured port is displayed in the popup for easy verification.

Note: Make sure your Draw.io MCP Server is running on the same port you configure here. Restarting the browser will not reset the configuration - it persists across sessions.

Connection Status

The extension icon indicates the current connection state:

• 🟢 Green: Connected to the server
• 🟠 Orange: Connecting/reconnecting
• 🔴 Red: Disconnected

You can also view the current configured port and connection status in the extension popup.
