BetterDB Monitor

A monorepo application for monitoring Valkey/Redis databases with a NestJS backend and React frontend.

BetterDB is built by BetterDB Inc., a public benefit company operating under the OCV Open Charter.

Project Structure

betterdb-monitor/
├── apps/
│   ├── api/                 # NestJS backend (Fastify)
│   └── web/                 # React frontend (Vite)
├── packages/
│   ├── cli/                 # CLI package (npx betterdb)
│   └── shared/              # Shared TypeScript types
├── docker-compose.yml       # Local Valkey (port 6380) and Redis (port 6382) for testing
└── package.json             # Workspace root

Tech Stack

Backend

• NestJS with Fastify adapter
• iovalkey for Valkey/Redis connections
• TypeScript with strict mode
• Runs on port 3001

Frontend

• React with TypeScript
• Vite for build tooling
• TailwindCSS for styling
• Recharts for data visualization
• Runs on port 5173

Monorepo

• pnpm workspaces for dependency management
• Turborepo for build orchestration

Quick Start

Prerequisites

• Node.js >= 20.0.0
• pnpm >= 9.0.0
• Docker (for local Valkey or Redis instances)

Installation

1. Install dependencies:

pnpm install

2. Copy environment variables:

cp .env.example .env

3. Start local database instances (Valkey on 6380, Redis on 6382):

pnpm docker:up

To connect to Redis instead of Valkey, update .env:

DB_PORT=6382

4. Start development servers:

pnpm dev

The application will be available at:

• Frontend: http://localhost:5173
• Backend API: http://localhost:3001

Individual Commands

Run only the API:

pnpm dev:api

Run only the web frontend:

pnpm dev:web

Stop Docker containers:

pnpm docker:down

Build for production:

pnpm build

CLI Installation (npx)

The easiest way to run BetterDB Monitor without Docker:

npx @betterdb/monitor

On first run, an interactive setup wizard will guide you through configuration:

• Database connection (host, port, credentials)
• Storage backend (SQLite, PostgreSQL, or in-memory)
• Server port and other settings

Configuration is saved to ~/.betterdb/config.json.

Global Installation

npm install -g @betterdb/monitor
betterdb

CLI Options

betterdb --setup           # Re-run setup wizard, then start server
betterdb --port 8080       # Override server port
betterdb --db-host 1.2.3.4 # Override database host
betterdb --help            # Show all options

SQLite Storage (Optional)

To use SQLite storage with the CLI, install better-sqlite3:

npm install -g better-sqlite3

Requirements

• Node.js >= 20.0.0
• A Valkey or Redis instance to monitor

Docker Production Deployment

Building the Docker Image

pnpm docker:build

For multi-arch builds (AMD64 + ARM64), first set up buildx:

docker buildx create --name mybuilder --use --bootstrap

Then build:

pnpm docker:build:multiarch

Running the Docker Container

The Docker image contains only the monitoring application (backend + frontend). It requires:

1. A Valkey/Redis instance to monitor
2. A PostgreSQL instance for data persistence (or use memory storage)

Basic Run (Memory Storage)

docker run -d \
  --name betterdb-monitor \
  -p 3001:3001 \
  -e DB_HOST=your-valkey-host \
  -e DB_PORT=6379 \
  -e DB_PASSWORD=your-password \
  -e STORAGE_TYPE=memory \
  betterdb/monitor

Run on Custom Port

You can run the application on any port by setting the PORT environment variable with -e PORT=<port>:

docker run -d \
  --name betterdb-monitor \
  -p 8080:8080 \
  -e PORT=8080 \
  -e DB_HOST=your-valkey-host \
  -e DB_PORT=6379 \
  -e DB_PASSWORD=your-password \
  -e STORAGE_TYPE=memory \


... [View full README on GitHub](https://github.com/BetterDB-inc/monitor#readme)
