OpenPencil

Open-source design editor. Opens .fig and .pen design files, includes built-in AI, and ships as a programmable toolkit with a headless Vue SDK for building custom editors.

Status: Active development. Not ready for production use.

Note: There is another open-source project with the same name — OpenPencil by ZSeven-W, focused on AI-native design-to-code workflows. This project focuses on Figma-compatible visual design with real-time collaboration.

Try it online → · Download · Documentation · llms.txt

Installation

macOS (Homebrew):

brew install openpencil

Or download from the releases page, or use the web app — no install needed.

What it does

• Opens .fig and .pen files — read and write native Figma files, open supported Pencil documents from the app or OS file browser, copy & paste nodes between apps
• AI builds designs — describe what you want in chat, 90+ tools create and modify nodes. Connect OpenRouter, Anthropic, OpenAI, Google AI, Z.ai, MiniMax, or compatible endpoints
• Fully programmable — headless CLI, XPath queries, Figma Plugin API via eval, MCP server for AI agents, and desktop agent integrations for Claude Code, Codex, and Gemini CLI
• Lint, convert, and extract tokens — inspect documents, lint naming/layout/accessibility, convert between supported formats, analyze colors/typography/spacing/clusters, and extract design tokens
• Components and variants — create reusable components, group variants into component sets, insert local assets as instances, and switch variants from the inspector
• Design-to-code export — export selections as JSX/Tailwind, generate token outputs, and map designs into component-oriented code workflows
• Vue SDK for custom editors — headless components and composables for embedding OpenPencil into other apps or building workflow-specific editing surfaces. Read the SDK docs →
• Real-time collaboration — P2P via WebRTC, no server, no account. Cursors, presence, follow mode
• Auto layout & CSS Grid — flex and grid layout via Yoga WASM, with gap, padding, alignment, track sizing
• ~7 MB desktop app — Tauri v2 for macOS, Windows, Linux. Also runs in the browser as a PWA

CLI

npm install -g @open-pencil/cli
# or: bun add -g @open-pencil/cli

Inspect design files

Browse node trees, search by name or type, dig into properties — all without opening the editor:

openpencil tree design.fig
openpencil find design.pen --type TEXT
openpencil node design.fig --id 1:23
openpencil info design.fig

[0] [page] "Getting started" (0:46566)
  [0] [section] "" (0:46567)
    [0] [frame] "Body" (0:46568)
      [0] [frame] "Introduction" (0:46569)
        [0] [frame] "Introduction Card" (0:46570)
          [0] [frame] "Guidance" (0:46571)

Query with XPath

Use XPath selectors to find nodes by type, attributes, and structure:

openpencil query design.fig "//FRAME"                              # All frames
openpencil query design.fig "//FRAME[@width < 300]"                # Frames under 300px
openpencil query design.fig "//TEXT[contains(@name, 'Button')]"     # Text with 'Button' in name
openpencil query design.fig "//*[@cornerRadius > 0]"               # Rounded corners
openpencil query design.fig "//SECTION//TEXT"                       # Text inside sections

Export

Render to PNG, JPG, WEBP, SVG, .fig, or JSX — or export selections/pages as .fig and convert whole documents between supported formats:

openpencil export design.fig                           # PNG
open
